T-23DT

Dual Temperature Reach-In

Product ID/SKU:
Price: $ Please call 330-339-6312 for pricing!


Stainless steel front, anodized aluminum ends, back and top. Interior of attractive white aluminum and stainless steel floor. Oversized and balanced (134A/R404A), refrigeration system, factory sealed and pre-lubricated for standard. Compartmentalized, incandescent interior lighting on solid door models, fluorescent in glass door models. T-23DT features refrigerator on top and freezer on bottom. T-49DT features refrigerator on left and freezer on right side. 4" swivel castors.

Refrig./Frzr. Doors Number of Shelves HP
Amps Exterior Dimensions
Solid Doors: Ref. | Frzr. L               D               H
T-23DT 2 3 1/10 | 1/3 6.3 27"       x 29 1/2" x 78 3/8"
T-49DT* 2 6 1/3   | 1/3 14.1 54 1/8" x 29 1/2" x 78 3/8"
Glass Doors:
T-23DT-G 2 3 1/5   | 1/2 15.6 27"       x 29 3/4" x 78 3/8"
Solid Half-Doors:
T-49DT-4* 4 6 1/3    | 1/3 14.1 54 1/8" x 29 1/2" x 78 3/8"

* Requires 115/208-230/60 Hz, single phrase, 3 pole, 4 wire circuit. T-49DT and T-49DT-4 are not CSA Rated

Height does not include 5" for castors or 6" for optional legs.  Depth does not include 1 3/8" door handle (glass door model only).


Highslide JS
T-49DT

T-49DT

Highslide JS
T-23DT-G

T-23DT-G

Highslide JS
T-49DT-4

T-49DT-4

<
